TCPA Omni-UL 90185A-801-04-N – 70V UL 1480 Wide-Area Emergency Communication Loudspeaker (Grey, No Label, 129dB)

Be the first to review this product

MODEL: 90185A-801-04-N

Regular Price: $5,514.88

Special Price: $4,914.88

Add to Cart

OR

Product Features

Key Features



  • UL 1480 Type FULC certified loudspeaker

  • Complies with S541 / CSA 22.2 No. 205 standards

  • 70V distributed audio system compatibility

  • Power tap options: 50W / 100W / 200W

  • 129 dB SPL high-output performance

  • Coverage up to 1/4 mile radius

  • Voice-optimized 350Hz–5kHz frequency response

  • 0.85 STI rating for superior speech intelligibility

  • Omni-directional sound projection

  • 22 lb enclosure

  • 19” diameter design

  • Grey housing with no label

  • Indoor and outdoor mass notification applications

TCPA Omni-UL 90185A-801-04-N – 70V UL 1480 Wide-Area Emergency Communication Loudspeaker (Grey, No Label, 129dB)

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • TCPA Omni-UL 90185A-801-04-N – 70V UL 1480 Wide-Area Emergency Communication Loudspeaker (Grey, No Label, 129dB)

Details

Designed for large-scale facilities, the TCPA Omni-UL 90185A-801-04-N provides omni-directional sound coverage for reliable mass notification in both interior and exterior environments. Operating on 70V systems, this UL 1480 Type FULC certified loudspeaker supports selectable wattage from 50 to 200 watts, allowing flexible system configuration.

With an acoustic output of 129 dB SPL and a communication radius of up to 1/4 mile, the TCPA Omni delivers powerful voice announcements and high-impact warning tones. Its 350Hz–5kHz frequency range is engineered for speech clarity, achieving an impressive STI score of 0.85.

At only 22 pounds and 19 inches in diameter, this grey, no-label model combines compact construction with high-output performance. Its strong acoustic projection reduces the number of speakers required across expansive industrial sites, improving intelligibility while lowering installation and maintenance demands.

Recommended for campus-wide alerts, manufacturing facilities, warehouses, airports, arenas, and corporate campuses.
